They are labeled alphabetically to represent their location from front to rear. The floor pan will also have several grooves and holes to fit the vehicle's' drivetrain and electric wiring.Ī-B-C-Pillars: These are the vertical supports of the car. The firewall alongside the apron, Strut tower, front rails and core support make up the front unibody and engine bay of a car.įloor pan: Is a metal sheet that is welded to several cross members to form the floor of a vehicle. The front of the apron extends from the core support to the strut tower and the rear apron extends from the strut tower to the firewall.įirewall: This is the part of the frame that separates the motor from the cockpit. They are designed to align and hold your vehicle's suspension in place.Īpron: This is the front inner fender area of the vehicle with two sides. The strut tower is also part of the front apron and rear quarter panel.
Strut tower: Every vehicle has four strut towers that are typically located on the four corners for the car. These rails are one of the strongest parts of the frame and are also the foundation for other components that will get welded onto these rails lie the apron for example. Unirail: Two symmetrical metal beams Located at the front and back of the car. In some vehicles, this part is bolted on and can be removed or replaced without being considered “Frame Damage” Which means the car might not drive straight and it will be weaker after repairs in the area where it's been damaged.Ĭore support: Also known as the radiator support, this section of the frame can be found on the front end of your car. If the Unibody frame of a vehicle is damaged it may result in a bent frame on a car. This type of frame can be broken down into several parts to describe their location and purpose. Meaning that the body and frame of the vehicle car are one. One of the most common forms of a vehicle's frame is a unibody. The most common are unibody frames & ladder frames. What are the different types of frames?Īlmost every car has a unique frame designed by the manufacturer but there are many different types of frame. When there is frame damage reported, this means there may be damage to parts of the vehicle that provide structural support. The term “Frame Damage” is used whenever the integrity of your frame has been compromised by either an accident or 3rd party alteration. It's designed to protect you in case of an accident and it's the foundation that your car is built on. What is a Frame Damaged Car?ĭeep down beneath all the parts in your car, there is a structural support system AKA the frame of your car. Before you start any repairs check the value of the car and see if the repairs are worth it. If you have unibody damage that isn't worth it to repair, you can sell your car in 24-48 hours online!įrame Damage can cost you more to fix than what the car is worth. They are designed to literally fold in like an accordion after a crash from to absorb the energy of an impact. They’re typically found in the front engine bay and in the rear support of the car. These are indented sections of the frame that make a light wavy shape. Most unibody vehicles have what is called crumple zones. In this article, we will cover these questions and more. Is it worth fixing my car after an accident? How much does it cost to fix a car with frame damage? If your car has sustained any heavy physical damage, then you may have some of these questions. Before embarking on the long and expensive journey of repairing a vehicle’s frame it's important to be well informed of what Frame damage is and what it means to make the smart decision. Coming out of an accident unharmed would be one lucky day but your car won't have that luck, there's a good chance you have just damaged the structural frame of the car and it might never drive or be as safe again. You see the fenders crumpled up like accordions, the radiator support smashed up onto the engine, and there are two metal beams sticking out at you like sore thumbs.
Imagine your vehicle was involved in a heavy front end collision. Your best bet would be comparing your options by getting a quote for your damaged car to see if it's worth throwing money in to repair it. Your entire vehicle is thrown out of alignment, and since bends in a frame can be expensive to repair, it might not be worth it. How Do I Know if My Car has Frame Damage?įrame damage on a car can be devastating.
